iPhone 17 Pro Max Specifications

Complete Apple iPhone 17 Pro Max technical specifications · Released 2025 · model numbers, colors, storage, dimensions and hardware details.

Chip: A19 Pro chip; 6‑core CPU with 2 performance and 4 efficiency cores; 6‑core GPU with Neura… Display: Super Retina XDR display; 6.9‑inch (diagonal) all‑screen OLED display; 2868‑by‑1320-pixel… Camera: 48MP Pro Fusion camera system; 48MP Fusion Main: 24 mm, ƒ/1.78 aperture, second‑generatio… IP68
Check IMEI / Serial All specs
Display
Super Retina XDR display; 6.9‑inch (diagonal) all‑screen OLED display; 2868‑by‑1320-pixel resolution at 460 p…
Chip
A19 Pro chip; 6‑core CPU with 2 performance and 4 efficiency cores; 6‑core GPU with Neural Accelerators; 16‑core Neural…
Storage / Colors
256GB, 512GB, 1TB, 2TB · Silver, Cosmic Orange, Deep Blue, Aluminum unibody design
Weight / OS
233 g · iOS

Apple iPhone 17 Pro Max technical specifications

This page contains complete technical specifications for Apple iPhone 17 Pro Max, including display, chip, storage, colors, model numbers, dimensions, weight, operating system, connectivity, battery information and other hardware details.

Use this information to compare Apple devices, identify the exact model, check compatibility and verify key hardware features before service, repair, resale or purchase.

iFinish

  • Silver
  • Cosmic Orange
  • Deep Blue
  • Aluminum unibody design, Ceramic Shield 2 front, Ceramic Shield back

▣Display

  • Super Retina XDR display
  • 6.9‑inch (diagonal) all‑screen OLED display
  • 2868‑by‑1320-pixel resolution at 460 ppi
  • Dynamic Island
  • Always-On display
  • ProMotion technology with adaptive refresh rates up to 120Hz
  • HDR display
  • True Tone
  • Wide color (P3)
  • Haptic Touch
  • 2,000,000:1 contrast ratio (typical)
  • 1000 nits max brightness (typical); 1600 nits peak brightness (HDR); 3000 nits peak brightness (outdoor); 1 nit minimum brightness
  • Fingerprint-resistant oleophobic coating
  • Anti-reflective coating
  • Support for display of multiple languages and characters simultaneously
  • The iPhone 17 Pro Max display has rounded corners that follow a beautiful curved design, and these corners are within a standard rectangle. When measured as a standard rectangular shape, the screen is 6.86 inches diagonally (actual viewable area is less).

⚙Chip

  • A19 Pro chip
  • 6‑core CPU with 2 performance and 4 efficiency cores
  • 6‑core GPU with Neural Accelerators
  • 16‑core Neural Engine
  • Hardware‑accelerated ray tracing

◉Camera

  • 48MP Pro Fusion camera system
  • 48MP Fusion Main: 24 mm, ƒ/1.78 aperture, second‑generation sensor‑shift optical image stabilization, 100% Focus Pixels, support for super‑high‑resolution photos (24MP and 48MP)
  • Also enables 12MP optical-quality 2x Telephoto: 48 mm, ƒ/1.78 aperture, second‑generation sensor‑shift optical image stabilization, 100% Focus Pixels
  • 48MP Fusion Ultra Wide: 13 mm, ƒ/2.2 aperture and 120° field of view, Hybrid Focus Pixels, super‑high‑resolution photos (48MP)
  • 48MP Fusion Telephoto: 100 mm (4x), ƒ/2.8 aperture, Hybrid Focus Pixels, 3D sensor‑shift optical image stabilization and autofocus, tetraprism design
  • Also enables 12MP optical-quality 8x Telephoto: 200 mm, ƒ/2.8 aperture, Hybrid Focus Pixels, 3D sensor‑shift optical image stabilization and autofocus, tetraprism design
  • 8x optical‑quality zoom in, 2x optical zoom out; 16x optical‑quality zoom range
  • Digital zoom up to 40x
  • Customizable default lens (Fusion Main)
  • Sapphire crystal lens cover
  • Adaptive True Tone flash
  • Photonic Engine
  • Deep Fusion
  • Smart HDR 5
  • Next-generation portraits with Focus and Depth Control
  • Portrait Lighting with six effects
  • Night mode
  • Panorama (up to 63MP)
  • Latest-generation Photographic Styles
  • Spatial photos
  • 48MP macro photography
  • ProRAW
  • Wide color capture for photos and Live Photos
  • Lens correction (Fusion Ultra Wide)
  • Advanced red-eye correction
  • Auto image stabilization
  • Burst mode
  • Photo geotagging
  • Image formats captured: HEIF, JPEG, and DNG

iVideo Recording

  • 4K Dolby Vision video recording at 24 fps, 25 fps, 30 fps, 60 fps, 100 fps (Fusion Main), or 120 fps (Fusion Main)
  • 1080p Dolby Vision video recording at 25 fps, 30 fps, 60 fps, or 120 fps (Fusion Main)
  • 720p Dolby Vision video recording at 30 fps
  • Cinematic mode up to 4K Dolby Vision at 30 fps
  • Action mode up to 2.8K Dolby Vision at 60 fps
  • Spatial video recording at 1080p at 30 fps
  • ProRes video recording up to 4K at 120 fps with external recording
  • ProRes RAW5
  • Academy Color Encoding System
  • Apple Log 2
  • Genlock support6
  • Macro video recording, including slo‑mo and time‑lapse
  • Slo‑mo video support for 1080p up to 240 fps and 4K Dolby Vision up to 120 fps (Fusion Main)
  • Dual Capture up to 4K Dolby Vision at 30 fps
  • Time‑lapse video with stabilization
  • Night mode Time‑lapse
  • QuickTake video up to 4K Dolby Vision at 60 fps
  • Second‑generation sensor‑shift optical image stabilization for video (Fusion Main)
  • 3D sensor‑shift optical image stabilization and autofocus for video (Fusion Telephoto)
  • Digital zoom up to 15x
  • Audio zoom
  • True Tone flash
  • Cinematic video stabilization (4K, 1080p, and 720p)
  • Continuous autofocus video
  • Take 8MP still photos while recording 4K video
  • Playback zoom
  • Video formats recorded: HEVC, H.264, ProRes, and ProRes RAW
  • Spatial Audio and stereo recording
  • Four studio-quality mics
  • Wind noise reduction
  • Audio Mix

iCharging and Expansion

  • USB-C connector with support for:
  • Charging
  • DisplayPort
  • USB 3 (up to 10Gb/s)15

iSensors

  • Face ID
  • LiDAR Scanner
  • Barometer
  • High dynamic range gyro
  • High-g accelerometer
  • Proximity sensor
  • Dual ambient light sensors

⌁Cellular and Wireless

  • FDD-5G NR (Bands n1, n2, n3, n5, n7, n8, n12, n14, n20, n25, n26, n28, n29, n30, n66, n70, n71, n75)
  • TDD-5G NR (Bands n38, n40, n41, n48, n53, n77, n78, n79)
  • 5G NR mmWave (Bands n258, n260, n261)
  • FDD-LTE (Bands 1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28, 29, 30, 32, 66, 71)
  • TDD-LTE (Bands 34, 38, 39, 40, 41, 42, 48, 53)
  • UMTS/HSPA+/DC-HSDPA (850, 900, 1700/2100, 1900, 2100 MHz)
  • GSM/EDGE (850, 900, 1800, 1900 MHz)
  • 5G (sub-6 GHz and mmWave) with 4x4 MIMO11
  • Gigabit LTE with 4x4 MIMO11
  • Wi‑Fi 7 (802.11be) with 2x2 MIMO12
  • Bluetooth 6
  • Thread networking technology
  • NFC with reader mode
  • Express Cards with power reserve
  • For details on 5G and LTE support, contact your carrier and see apple.com/iphone/cellular.

iSIM Card

  • Dual eSIM (two active eSIMs; stores eight or more eSIMs)16
  • iPhone 17 Pro and iPhone 17 Pro Max use advanced eSIM technology for more convenience and security (not compatible with physical SIM cards).
  • Learn more about eSIMLearn more about traveling with eSIM

iLocation

  • Precision dual-frequency GPS (GPS, GLONASS, Galileo, QZSS, BeiDou, and NavIC)
  • Digital compass
  • Wi-Fi
  • Cellular
  • iBeacon microlocation

iAudio Playback

  • Supported formats include AAC, APAC, MP3, Apple Lossless, FLAC, Dolby Digital, Dolby Digital Plus, and Dolby Atmos
  • Spatial Audio playback
  • User‑configurable maximum volume limit

iVideo Playback

  • Supported formats include HEVC, H.264, AV1, and ProRes
  • HDR with Dolby Vision, HDR10+/HDR10, and HLG
  • Up to 4K HDR AirPlay for mirroring, photos, and video out to Apple TV (2nd generation or later) or AirPlay‑enabled smart TV
  • Video mirroring and video out support: Up to 4K HDR through native DisplayPort output over USB-C or USB-C Digital AV Adapter (model A2119; adapter sold separately)20

⌁External Buttons and Connectors

  • Volume up/down
  • Action button
  • Camera Control
  • Side button
  • USB-C connector
  • Built‑in microphones
  • Built‑in stereo speaker
  • Action button features
  • Silent mode, Focus, Camera, Visual Intelligence,14 Flashlight, Voice Memo, Recognize Music, Translate, Magnifier, Controls, Shortcut, or Accessibility
  • Camera controls
  • Exposure, Depth, Zoom, Cameras, Styles, Tone

iOperating System

  • iOS
  • iOS is the world’s most personal and secure mobile operating system, packed with powerful features and designed to protect your privacy.

iAccessibility

  • Built-in accessibility features supporting vision, mobility, hearing, speech, and cognitive needs help you get the most out of your iPhone — in the ways that work best for you.
  • Learn more about Accessibility
  • Features include:
  • VoiceOver
  • Zoom
  • Magnifier
  • Voice Control
  • Switch Control
  • AssistiveTouch
  • Eye Tracking
  • RTT and TTY support
  • Closed Captions
  • Live Captions
  • Personal Voice
  • Live Speech
  • Type to Siri
  • Vocal Shortcuts
  • Spoken Content

iBuilt-in Apps

  • App Store
  • Books
  • Calculator
  • Calendar
  • Camera
  • Clock
  • Compass
  • Contacts
  • FaceTime
  • Files
  • Find My
  • Fitness
  • Freeform
  • Games
  • GarageBand
  • Health
  • Home
  • iMovie
  • iTunes Store
  • Journal
  • Keynote
  • Magnifier
  • Mail
  • Maps
  • Measure
  • Messages
  • Music
  • News
  • Notes
  • Numbers
  • Pages
  • Passwords
  • Phone
  • Photos
  • Podcasts
  • Preview
  • Reminders
  • Safari
  • Settings
  • Shortcuts
  • Stocks
  • Tips
  • Translate
  • TV
  • Voice Memos
  • Wallet
  • Watch
  • Weather
  • For a complete list of Apple apps available on iPhone, see apple.com/apps.

iSystem Requirements

  • Apple Account (required for some features)
  • Internet access22
  • Syncing to a Mac or PC requires:
  • macOS Catalina 10.15 or later using the Finder
  • macOS High Sierra 10.13 through macOS Mojave 10.14.6 using iTunes 12.8 or later
  • Windows 10 or later using iTunes 12.12.10 or later (free download from apple.com/itunes/download)

iEnvironmental Requirements

  • Operating ambient temperature: 32° to 95° F (0° to 35° C)
  • Nonoperating temperature: −4° to 113° F (−20° to 45° C)
  • Relative humidity: 5% to 95% noncondensing
  • Operating altitude: tested up to 10,000 feet (3000 m)

iLanguages

  • Language support
  • English (Australia, UK, U.S.), Chinese (Simplified, Traditional, Traditional – Hong Kong), French (Canada, France), German, Italian, Japanese, Korean, Spanish (Latin America, Spain), Arabic, Bulgarian, Catalan, Croatian, Czech, Danish, Dutch, Finnish, Greek, Hebrew, Hindi, Hungarian, Indonesian, Kazakh, Malay, Norwegian, Polish, Portuguese (Brazil, Portugal), Romanian, Russian, Slovak, Swedish, Thai, Turkish, Ukrainian, Vietnamese
  • Learn more about feature availability

iIn the Box

  • iPhone 17 Pro Max
  • USB‑C Charge Cable (1 m)
  • Documentation
  • As part of our efforts to reach carbon neutrality by 2030, iPhone 17 Pro and iPhone 17 Pro Max do not include a power adapter or EarPods. Included in the box is a USB‑C Charge Cable that supports fast charging and is compatible with USB‑C power adapters and computer ports.
  • We encourage you to use any compatible USB‑C power adapter. If you need a new Apple power adapter or headphones, they are available for purchase.

iApple Intelligence

  • Apple Intelligence is integrated across your apps and experiences to help you communicate, express yourself, and get things done effortlessly. With groundbreaking privacy protections, it gives you peace of mind that no one else can access your data — not even Apple.4
  • Learn more about Apple Intelligence

iApple Pay

  • Pay with your iPhone using Face ID in stores, within apps, and on the web
  • Send and receive money in Messages with Apple Cash17
  • Complete purchases made with Apple Pay on your Mac
  • Pay for your ride using Express Transit18
  • Learn more about Apple PayLearn more about Apple Cash

iAudio Calling19

  • FaceTime audio
  • Voice over LTE (VoLTE)11
  • Wi‑Fi calling11
  • SharePlay
  • Screen sharing
  • Spatial Audio
  • Voice Isolation and Wide Spectrum microphone modes

iCapacity1

  • 256GB
  • 512GB
  • 1TB
  • 2TB

iFace ID

  • Enabled by TrueDepth technology in the Center Stage front camera

◉Front Camera

  • 18MP Center Stage camera
  • ƒ/1.9 aperture
  • Autofocus with Focus Pixels
  • Retina Flash
  • Tap to zoom and rotate
  • Center Stage for photos
  • Ultra-stabilized video
  • Dual Capture
  • Center Stage for video calls
  • Photonic Engine
  • Deep Fusion
  • Smart HDR 5
  • Next-generation portraits with Focus and Depth Control
  • Portrait Lighting with six effects
  • Animoji and Memoji
  • Night mode
  • Latest-generation Photographic Styles
  • ProRAW
  • Wide color capture for photos and Live Photos
  • Lens correction
  • Auto image stabilization
  • Burst mode
  • 4K Dolby Vision video recording at 24 fps, 25 fps, 30 fps, or 60 fps
  • 1080p Dolby Vision video recording at 25 fps, 30 fps, or 60 fps
  • Cinematic mode up to 4K Dolby Vision at 30 fps
  • ProRes video recording up to 4K at 60 fps with external recording
  • ProRes RAW5
  • Academy Color Encoding System
  • Apple Log 2
  • Slo-mo video support for 1080p at 120 fps
  • Time‑lapse video with stabilization
  • Night mode Time-lapse
  • QuickTake video up to 4K at 60 fps in Dolby Vision
  • Cinematic video stabilization (4K, 1080p, and 720p)
  • Spatial Audio and stereo recording
  • Wind noise reduction
  • Audio Mix

iiPhone and the Environment

  • iPhone 17 Pro and iPhone 17 Pro Max are designed to reduce environmental impact:23
  • See the iPhone 17 Pro and iPhone 17 Pro Max Product Environmental Report (PDF)
  • Progress toward Apple 2030
  • Apple 2030 is our commitment to be carbon neutral for our entire carbon footprint. Our plan to decarbonize products is rigorous and focuses on transitioning to low‑carbon electricity, designing with recycled and low‑carbon materials, and prioritizing lower‑carbon ways of shipping products, like ocean freight.
  • See Apple’s commitment
  • Materials
  • iPhone 17 Pro and iPhone 17 Pro Max are made with 30% recycled content,24 including:
  • 50% recycled aluminum in the enclosure
  • 100% recycled cobalt and 95% recycled lithium in the battery
  • 100% recycled gold plating and tin solder in all Apple‑designed printed circuit boards
  • 100% recycled gold wire in all cameras and gold plating in all connectors
  • 100% recycled tungsten and copper wire in the Taptic Engine
  • 100% recycled copper in the vapor chamber enclosure
  • 100% recycled rare earth elements in all magnets
  • Energy
  • 40% of manufacturing electricity for iPhone 17 Pro and iPhone 17 Pro Max is sourced from renewable electricity25
  • Exceeds U.S. Department of Energy requirements for battery charger systems26
  • Packaging
  • 100% fiber-based packaging27
  • iPhone 17 Pro and iPhone 17 Pro Max packaging is designed to be more efficient than iPhone 16 Pro boxes, increasing the number of devices shipped per trip by 25%28
  • Waste
  • No established final assembly sites generate waste sent to landfill as part of Apple’s Zero Waste Program29
  • Smarter chemistry30
  • All of the materials used in Apple products, accessories, and packaging are covered by the requirements of our Regulated Substances Specification, which was one of the first in industry to restrict the use of key substances of concern. See the latest Environmental Progress Report to understand Apple’s recent efforts in phasing out these chemistries.

⌁MagSafe and Wireless Charging

  • MagSafe wireless charging up to 25W8
  • Qi2 wireless charging up to 25W8
  • Magnet array
  • Alignment magnet
  • Accessory Identification NFC
  • Magnetometer

iPeace of Mind

  • Emergency SOS via satellite9
  • Crash Detection10
  • Roadside Assistance via satellite9
  • Messages via satellite9
  • Find My via satellite9

⚡Power and Battery7

  • Video playback: Up to 39 hours
  • Video playback (streamed): Up to 35 hours
  • Built‑in rechargeable lithium‑ion battery
  • Fast-charge capable:
  • Up to 50% charge in 20 minutes8 with 40W adapter or higher (available separately) paired with USB-C charging cable
  • Up to 50% charge in 30 minutes8 with 30W adapter or higher paired with MagSafe Charger (both available separately)

iPrivacy

  • iPhone is built from the ground up to protect your personal information. Every iPhone has secure facial authentication. Apps need your permission to track your activity across other companies’ apps or websites. Your iMessages and FaceTime video calls are encrypted end-to-end. And much more.
  • Learn more about privacy features

iRating for Hearing Aids

  • Hearing Aid Compatible

iSiri21

  • Get help with everyday tasks like sending messages, setting reminders, and more
  • Activate hands‑free with only your voice using “Siri” or “Hey Siri,” or use Type to Siri
  • Protected by the strongest privacy of any intelligent assistant
  • Powered by Apple Intelligence, Siri is more natural and helpful4
  • Learn more about Siri

↔Size and Weight2

  • Width: 3.07 inches (78.0 mm)
  • Height: 6.43 inches (163.4 mm)
  • Depth: 0.34 inch (8.75 mm)
  • Weight: 8.22 ounces (233 grams)

iSplash, Water, and Dust Resistant3

  • Rated IP68 (maximum depth of 6 meters up to 30 minutes) under IEC standard 60529

iVideo Calling19

  • FaceTime video calling over cellular or Wi‑Fi
  • FaceTime HD (1080p) video calling over 5G or Wi‑Fi
  • Center Stage for video calling
  • SharePlay
  • Screen sharing
  • Portrait mode in FaceTime video
  • Spatial Audio
  • Voice Isolation and Wide Spectrum microphone modes
  • Optical zoom with rear‑facing camera

iPhone 17 Pro Max FAQ

What year was Apple iPhone 17 Pro Max released?

Apple iPhone 17 Pro Max was released in 2025.

What is the display size of Apple iPhone 17 Pro Max?

Apple iPhone 17 Pro Max has Super Retina XDR display; 6.9‑inch (diagonal) all‑screen OLED display; 2868‑by‑1320-pixel….

What chip does Apple iPhone 17 Pro Max use?

Apple iPhone 17 Pro Max uses A19 Pro chip; 6‑core CPU with 2 performance and 4 efficiency cores; 6‑core GPU with Neura….

What storage capacities are available for Apple iPhone 17 Pro Max?

Available storage capacities include 256GB, 512GB, 1TB, 2TB.

What are the model numbers for Apple iPhone 17 Pro Max?

Known model numbers include A2119, A3256, A3257, A3351, A3502, A3503, A2164.

Is Apple iPhone 17 Pro Max water resistant?

Apple iPhone 17 Pro Max has IP68 rating according to the saved technical specifications.
