Studio Display XDR Specifications

Complete Apple Studio Display XDR technical specifications · Released 2026 · model numbers, colors, storage, dimensions and hardware details.

Display: 5K Retina XDR display; 27-inch (diagonal) 5K Retina XDR display; 5120-by-2880 resolution … Camera: 12MP Center Stage camera with Desk View
Check IMEI / Serial All specs
Display
5K Retina XDR display; 27-inch (diagonal) 5K Retina XDR display; 5120-by-2880 resolution at 218 pixels per in…
Chip
—
Storage / Colors
120Gb, 10Gb · 5K Retina XDR display, 27-inch (diagonal) 5K Retina XDR display, 5120-by-2880 resolution at 218 pixels per inch, Mini-LED backlight with 2304 dimming zones
Weight / OS
8500 g · macOS

Apple Studio Display XDR technical specifications

This page contains complete technical specifications for Apple Studio Display XDR, including display, chip, storage, colors, model numbers, dimensions, weight, operating system, connectivity, battery information and other hardware details.

Use this information to compare Apple devices, identify the exact model, check compatibility and verify key hardware features before service, repair, resale or purchase.

↔Size and Weight

  • Studio Display XDR with tilt- and height-adjustable stand
  • Height (bottom position): 18.8 inches (47.8 cm)
  • Width: 24.5 inches (62.3 cm)
  • Height (top position): 23.0 inches (58.3 cm)
  • Weight: 18.7 pounds (8.5 kg)3
  • Depth: 8.4 inches (21.4 cm)
  • Studio Display XDR with VESA mount adapter
  • Height: 14.3 inches (36.2 cm)
  • Depth: 1.3 inches (3.3 cm)
  • Weight: 13.9 pounds (6.3 kg)3

▣Display

  • 5K Retina XDR display
  • 27-inch (diagonal) 5K Retina XDR display
  • 5120-by-2880 resolution at 218 pixels per inch
  • Mini-LED backlight with 2304 dimming zones
  • Up to 1000 nits brightness (SDR)
  • 2000 nits peak1 brightness (HDR)
  • 120Hz refresh rate and Adaptive Sync
  • Support for 1 billion colors
  • P3 + Adobe RGB wide color gamuts
  • True Tone technology
  • Configurable with:
  • Nano-texture glass

◉Camera

  • 12MP Center Stage camera with Desk View

iIn the Box

  • Studio Display XDR
  • Thunderbolt 5 Pro cable (1 m)

iAudio

  • High-fidelity six-speaker system with force-cancelling woofers
  • Wide stereo sound
  • Support for Spatial Audio when playing music or video with Dolby Atmos
  • Studio-quality three-mic array with high signal-to-noise ratio and directional beamforming
  • Support for “Hey Siri”

iCompatibility

  • Studio Display XDR is compatible with the following Mac models with Apple silicon and macOS Tahoe 26.3.1 or later:
  • 16-inch MacBook Pro (2021 and later)
  • 14-inch MacBook Pro (2021 and later)
  • 13-inch MacBook Pro (M1, 2020 and later)
  • 15-inch MacBook Air (2023 and later)
  • 13-inch MacBook Air (M1, 2020 and later)
  • Mac Studio (2022 and later)
  • Mac mini (2020 and later)
  • Mac Pro (2023 and later)
  • 24-inch iMac (2021 and later)
  • Mac models with M1, M1 Pro, M1 Max, M1 Ultra, M2, and M3 support Studio Display XDR at up to 60Hz. All other Studio Display XDR features are supported.
  • Studio Display XDR is compatible with the following iPad models with iPadOS 26.3.1 or later:4
  • iPad Pro (M4 and M5)
  • iPad Pro 12.9-inch (3rd–6th generation)
  • iPad Pro 11-inch (1st–4th generation)
  • iPad Air (M2, M3, and M4)
  • iPad Air (5th generation)
  • iPad Pro (M5) supports Studio Display XDR at 120Hz. All other compatible iPad models support it at 60Hz.

iConfigure to Order

  • Configure your Studio Display XDR with these options at apple.com:
  • Nano-texture glass
  • VESA mount adapter

⌁Connections

  • Two Thunderbolt 5 ports (up to 120Gb/s) and two USB-C ports (up to 10Gb/s)
  • One upstream Thunderbolt 5 port for host (with 140W host charging)
  • One downstream Thunderbolt 5 port for connecting high-speed accessories or daisy-chaining additional displays
  • Two USB-C ports (up to 10Gb/s) for connecting peripherals, storage, and networking

iElectrical and Operating Requirements

  • Line voltage: 100–240V AC
  • Frequency: 50Hz to 60Hz, single phase
  • Operating temperature: 50° to 95° F (10° to 35° C)
  • Relative humidity: 5% to 90% noncondensing
  • Maximum altitude: tested up to 16,400 feet (5000 meters)

iReference Modes

  • Available reference modes:
  • Apple XDR Display (P3-2000 nits)
  • Apple XDR Display (P3 + Adobe RGB-2000 nits)
  • HDR Video (P3-ST 2084)
  • HDTV Video (BT.709-BT.1886)
  • NTSC Video (BT.601 SMPTE-C)
  • PAL and SECAM Video (BT.601 EBU)
  • Digital Cinema (P3-DCI)
  • Digital Cinema (P3-D65)
  • Design and Print (P3-D50)
  • Design and Print (Adobe RGB-D50)
  • Photography (P3-D65)
  • Photography (Adobe RGB-D65)
  • HDR Photography (P3-D65)
  • Internet and Web (sRGB)
  • Medical Imaging (DICOM-350 nits)2
  • Medical Imaging (DICOM-600 nits)2

iStand

  • Tilt- and height-adjustable stand
  • Tilt: −5° to +25°
  • Height adjustment: total of 105 mm
  • Orientation: landscape
  • Configurable with:
  • VESA mount adapter
  • Compatible with 100 x 100 mm VESA stand
  • Orientation: landscape or portrait

▣Studio Display XDR and the Environment

  • Studio Display XDR is designed to reduce environmental impact:5
  • Progress toward Apple 2030
  • Apple 2030 is our commitment to be carbon neutral for our entire carbon footprint. Our plan to decarbonize products is rigorous and focuses on transitioning to low-carbon electricity, designing with recycled and low-carbon materials, and prioritizing lower-carbon ways of shipping products, like ocean freight.
  • See Apple’s commitment
  • Materials
  • 100% recycled aluminum in the stand
  • 100% recycled copper in multiple printed circuit boards
  • 100% recycled copper and zinc in the prongs of the power cord plug and AC inlet
  • 80% recycled glass in the standard glass
  • 100% recycled gold plating and tin solder in all Apple-designed printed circuit boards
  • 100% recycled rare earth elements in all magnets
  • Energy
  • ENERGY STAR® certified6
  • Packaging
  • 100% fiber-based packaging7
  • Waste
  • No established final assembly sites generate waste sent to landfill as part of Apple’s Zero Waste Program8
  • Smarter chemistry9
  • All of the materials used in Apple products, accessories, and packaging are covered by the requirements of our Regulated Substances Specification, which was one of the first in industry to restrict the use of key substances of concern. See the latest Environmental Progress Report to understand Apple’s recent efforts in phasing out these chemistries.

Studio Display XDR FAQ

What year was Apple Studio Display XDR released?

Apple Studio Display XDR was released in 2026.

What is the display size of Apple Studio Display XDR?

Apple Studio Display XDR has 5K Retina XDR display; 27-inch (diagonal) 5K Retina XDR display; 5120-by-2880 resolution ….

What storage capacities are available for Apple Studio Display XDR?

Available storage capacities include 120Gb, 10Gb.
